Time Series

Returns data for a station or set of stations based on a time span

Request Format

A Time Series request is an HTTP URL with the following form:

CODE
https://api.synopticdata.com/v2/stations/timeseries

Acquiring data from this web service requires certain parameters. When encoding URLs, all parameters are separated using the ampersand (&) character and their value is indicated by an equal sign (=). Below is a list of accepted parameters.

  • token (required), Your application’s API token. This is used to identify who is requesting API data. You are never required to use multiple tokens, but you can use as many as you need. Learn more in our tokens overview.

  • At least one station selection parameter (required):

Station Selection Parameters

These selectors individually or combined to target the desired stations.

Exclusion Operator

Selectors noted as (excludable) may be specified with a ! preceding a value to remove/exclude from the selection from a result set. So stid=!KSLC would prevent KSLC from returning in a query. This should be used in combination with different selectors. Remember to only include any given selector once.

stid

(string, excludable), Single or comma separated list of SynopticLabs station IDs. Use a ! before any value to exclude matching stations. Example: stid=mtmet,kslc,fps. Try it Now

state

(string, excludable), Single or comma separated list of abbreviated 2 character states. If country is not included, default is United States (US). Use a ! before any value to exclude matching stations. Example: state=ut,wy,dc.

country

(string, excludable), Single or comma separated list of abbreviated 2 or 3 character countries. Use a ! before any value to exclude matching stations. Example: country=us,ca,mx.

nwszone

(string, excludable), Single or comma separated list of National Weather Service Zones. Use a ! before any value to exclude matching stations. Example: nwszone=UT003,CA041.

nwsfirezone

(string, excludable), Single or comma separated list of National Weather Service Fire Zones. Use a ! before any value to exclude matching stations. Example: nwsfirezone=LOX241

cwa

(string, excludable), Single or comma separated list of National Weather Service County Warning Areas. Use a ! before any value to exclude matching stations. Example: cwa=LOX.

gacc

(string, excludable), Single or comma separated list of Geographic Area Coordination Centers. Use a ! before any value to exclude matching stations. Example: gacc=GB.

subgacc

(string, excludable), Single or comma separated list of Sub Geographic Area Coordination Centers. Use a ! before any value to exclude matching stations. Example: subgacc=EB07.

county

(string, excludable), Single or comma separated list of counties. Use the state parameter to filter by state in the case of duplicate county names (i.e. “King”). Use a ! before any value to exclude matching stations. Example: county=king&state=wa.

vars

(string), Single or comma separated list of sensor variables found here. The request will return all stations matching at least one of the variables provided. This is useful for filtering all stations that sense only certain variables, such as wind speed, or pressure. Do not specify vars twice in a query string. Some web services use this argument to adjust what information is delivered. Example: vars=wind_speed,pressure. Try it Now

varsoperator

(string), Define how &vars is understood. or (the default) means any station with any variable in the list is used. and means a station must report every variable to be included. Example: varsoperator=and.

network

(number, string, excludable), Single or comma separated list of network IDs or short names. The ID can be found be using the Networks service and are also listed here. Use a ! before any value to exclude specific networks from a result set. Example: network=153 or network=uunet,raws.

radius

(string), A comma separated list of three values of the type [latitude,longitude,miles] or [stn_id,miles]. Coordinates are in decimal degrees. Returns all stations within radius of the point (or station, given by the station ID) and provides the DISTANCE of the station from given location with units of miles. Adding limit=n to the query will limit the number of returned stations to n stations, and will order the stations by DISTANCE. Some examples are: radius=41.5,-120.25,20, radius=wbb,10, radius=41.5,-120.25,20&limit=10.

bbox

(string), A bounding box defined by the lower left and upper right corners in decimal degrees latitude and longitude coordinates, in the form of [lonmin,latmin,lonmax,latmax]. Recall that for regions involving the western and southern hemispheres that the coordinates are negative values (e.g., 120 W is -120, 20 S is -20). Example: bbox=-120,40,-119,41.

Bounding Box Thinning

A new feature allows you to use the API to thin the returned station set within a bounding box by providing some additional arguments. These arguments only take effect when the bbox parameter is used:

height

(number) the height of the map viewport in pixels

width

(number) the width of the map viewport in pixels

spacing

(number) the preferred number of pixels a station on the map should consume

networkimportance

(numbers, comma-separated) a list of comma separated network IDs that will be considered in the order provided. When there is a collision of stations within the defined “spacing” area, any station matching the list of preferred networks will be shown over any other.

status

(string), A value of either active or inactive returns only stations that are currently set as active in the archive. By default, omitting this parameter will return all stations. Example: status=active.

complete

(1, 0 [default]), A value of 1 or 0. When set to 1 an extended list of metadata attributes for each returned station is provided. This result is useful for exploring the zones and regions in which a station resides. Example: complete=1.

fields

(string), Case-insensitive comma-separated list of metadata attributes to include in the output response. Default is to include all attributes. Only works with attributes defined in the default metadata set (e.g. attributes shown via complete=1 cannot be selected). Example: fields=stid,name.

  • Either start and end, or recent (one is required but not both)

    • start & end, Defines the start and end time of the request with the form of YYYYmmddHHMM. Where YYYY is year, mm is month, dd is day, HH is hour, and MM is minutes. The start parameter must be used with the end parameter. For example: &start=201306011800&end=201306021215.

      All times are requested in UTC, but may be returned in either UTC or local time format for each station. See the obtimezone parameter.

    • recent, Indicates the number of minutes to return, previous to the current time. For example: recent=120 will return the last two hours of observations.

Optional Parameters

  • obtimezone (UTC [default], local), Indicates if the time zone of the response is in UTC or the local time zone of the station. Sets the time zone applied to the observation output (input times associated with start and end are always UTC). Example: obtimezone=local

  • showemptystations (0 [default], 1), Indicates if stations with no observations will be returned. Setting to 1 will return any station meeting the defined time period, variables, and geographic or network parameters, even if there are no observation data available.

  • showemptyvars (0 [default], 1), Indicates if variables with no observations for the requested time period will be returned. Default behavior is to remove any variables from the OBSERVATIONS element if no data is present. Setting to 1 will return keys in the OBSERVATIONS element for any requested variables. This guarantees that all keys in the SENSOR_VARIABLES element will be present in the OBSERVATIONS element. For the timeseries service, if other non-requested variables have reported for the requested time period, empty variables will be shown with null arrays. However if no station reports are present for the period empty variables will show empty lists ([]). Note that if all requested variables are empty you will also need to pass showemptystations=1 to retain the station and variables in the response.

  • units (metric [default], english, [custom format]), Defines the unit of measure for returned data. For standard measurements used by many in the United States english will fill most needs. There is also the ability to support custom unit configurations. This is achieved by accessing the variable group such as “temp” and setting the desired unit using a pipe (|) character. The following list describes the available units for each variable group.

    • temp (C, F, K), Temperature: Celsius, Fahrenheit and Kelvin.

    • speed (mps, mph, kph, kts), Speed/Velocity: Meters per second, miles per hour, kilometers per hour, knots.

    • pres (pa, mb, inhg), Pressure: Pascals, millibars, inches mercury.

    • height (m, ft), Height: Meters, feet.

    • precip (mm, cm, in), Precipitation: Millimeters, centimeters, inches.

    • alti (pa, inhg), Altimeter: Pascals, inches mercury.

    Furthermore, it is possible to modify one of the preset settings (metric/english). This is achieved by appending a variable group and unit to the parameter string with a comma. For example, to use “english” units with any speed variables in mph (instead of default knots) the parameter would be &units=english,speed|mph.

  • precip (0 [default], 1), Enable derived precip (Basic Precipitation Service). All raw precip variables will be replaced with two new variables named precip_intervals_set_1d and precip_accumulated_set_1d. precip_intervals_set_1d represents precip received in the intervals between consecutive observations. For ASOS stations, the intervals span between official 1-hr and special METAR reports. precip_accumulated_set_1d is a cumulative sum of the interval values for the requested time period. Note that precip values will only be reported for complete intervals contained within the requested start and end. If you are using this service to sum precip for consecutive requests, it is possible that intervals spanning the edges of your request window will not be counted (the Advanced Precipitation Service may be better suited for this request pattern). Passing vars=precip along with precip=1 enables return of derived precip without needing to specify an individual precip variable with vars=, or needing to return all reported variables for a station (omitting vars). Example: precip=1 or vars=precip&precip=1

  • all_reports (0 [default], 1), Indicates if reports from all available precipitation variables should be returned. Some networks (such as ASOS/AWOS) can report precipitation in multiple forms (e.g. precip_accum_one_hour and precip_accum_six_hour). By default, the derived precip returned with precip=1 will be calculated using the single most representative and consistently reporting variable. (requires precip=1 to be enabled)

  • hfmetars (0, 1 [default]) Disable use of High Frequency NOAA METAR data. This is a variant of the hourly NWS/FAA airport data where observations are recorded approximately every 5 minutes. A value of 0 will exclude these data from data returns.

  • sensorvars (0 [default], 1) Indicates if sensor specific metadata for each variable in the SENSOR_VARIABLES element will be returned. Each sensor element contains the following: a position value indicating the height of the sensor, a PERIOD_OF_RECORD value that describes the period of the sensor being active, and a derived_from list of source observations (derived variables only). By default (0), empty objects will be returned within the SENSOR_VARIABLES element, with the exception derived variables which will always show derived_from keys.

The following example will request all the stations in Utah with an observation within the last two hours:

CODE
https://api.synopticdata.com/v2/stations/timeseries?state=ut&recent=120&token=YOUR_TOKEN_HERE

The following example will request only the air temperature for KSLC (Salt Lake City Airport) on January 3, 2015:

CODE
https://api.synopticdata.com/v2/stations/timeseries?stid=kslc&start=201501030000&end=201501032359&vars=air_temp&token=YOUR_TOKEN_HERE

Response Format Parameters

  • timeformat, Defines a time format that all time stamps in the data response to be formatted to. By default the API will return time values in ISO 8601 format. This behavior can be changed by passing a string with a valid strftime expression. Below are some common examples.

    • timeformat=%m/%d/%Y at %H:%M would yield “06/22/2017 at 17:06”

    • timeformat=%b%20%d%20%Y%20-%20%H:%M would yield “Jun 22 2017 - 17:06”

    • timeformat=%s returns Unix/POSIX time in terms of seconds (this parameter cannot be used with obtimezone). This is a special function in addition to the supported strftime arguments.

  • output (json [default], csv, xml, geojson), Indicates the response format of the request. It’s recommended to use the JSON format which there are well supported parsing libraries in all major languages.

    • csv only works when requesting a single station. i.e using the stid parameter.

    • geojson will only return the best guess sensor if the station has multiple sensors of the same type.

Data Checks and Quality Control

By default, the API does not return data that has been flagged as non-plausible by the Synoptic Range Check, e.g. a temperature value of 200°C.

If the qc parameter is omitted then the API will return data while assuming the following: qc=on, qc_remove_data=on, qc_flags=off and qc_checks=sl_range_check. Note that if the range check removes all values for all requested stations and variables, a response message of “No stations found for this request” will be returned. If the range check removes all values only for certain variables, those variables will not be present in the OBSERVATIONS object.

Note: The existence of a data check flag for an observation is not necessarily an indication of invalid or inaccurate data. For a detailed explanation of data checks, please click here to read more.

  • qc (on [default], off), Indicates the application behavior of the QC attributes on the data requested. If set to off then all data will be returned without data checks and quality control (not recommended). If set to on, a QC_SUMMARY object is returned, a QC_FLAGGED: [bool] key will be inside the STATION object, and individual data checks will be in the qc response key for each variable within the OBSERVATIONS object.

  • qc_remove_data (on, off, mark), Indicates the response behavior for an observation that fails a user specified data check. (default on if qc parameter omitted, else off if qc=on)

    • off returns the data values even if a data check failure is present for that data.

    • on removes failed data values, returning null. If all values for all requested stations and variables are set to null, a response message of “No stations found for this request” will be returned. If all values for an individual variable are set to null, the variable will not be present in the OBSERVATIONS object.

    • mark replaces failed data with a value of false.

  • qc_flags (on, off), Indicates whether the data checks are returned alongside any data that failed a requested check. If on then the data checks will be returned in the qc response key for each variable within the OBSERVATIONS block. (default off if qc parameter omitted, else on if qc=on)

  • qc_checks ([flag name], [flag source], keyword), defines a list of applied data checks. (defaults to sl_range_check if qc parameter omitted, else synopticlabs if qc=on)

    • “flag name” allows targeting one or more specific data checks in a comma separated list (e.g. sl_range_check,sl_rate_check)

    • “flag source” allows targeting one or more data check providers (synopticlabs, mesowest or madis).

    • “keyword” can be one of the following: basic,advanced, all. Click here to read more about the basic and advanced groups of checks).all will apply all data checks in our system. Caution: This argument will enable all flag sources, some of which can aggressively flag data, and may remove significant amounts of data if qc_remove_data=on.

Some examples of modifying the default QC checks are:

  • qc_checks=synopticlabs,ma_range_check, Applies the Synoptic QC suite and MADIS range check

  • qc_checks=synopticlabs,madis, Applies the Synoptic and MADIS QC suites.

Request Response

JSON Format

The Time Series service will return its results in a single organized and self describing JSON object. At a minimum, every request will return a JSON object with a SUMMARY field.

An example JSON response would be:

JSON
{
  UNITS: {
    position: "m",
    elevation: "ft",
    air_temp: "Celsius"
  },
  QC_SUMMARY: {
    QC_CHECKS_APPLIED: [
      "sl_range_check"
    ],
    TOTAL_OBSERVATIONS_FLAGGED: 0,
    PERCENT_OF_TOTAL_OBSERVATIONS_FLAGGED: 0
  },
  STATION: [
    {
      STATUS: "ACTIVE",
      MNET_ID: "1",
      PERIOD_OF_RECORD: {
        start: "1997-01-01T00:00:00Z",
        end: "2023-07-27T23:30:00Z"
      },
      ELEVATION: "4226",
      NAME: "Salt Lake City, Salt Lake City International Airport",
      STID: "KSLC",
      SENSOR_VARIABLES: {
        air_temp: {
          air_temp_set_1: {
            position: "2.0",
            PERIOD_OF_RECORD: {
              start: "1997-01-01T00:50:00Z",
              end: "2023-07-31T17:54:00Z"
            }
          }
        }
      },
      ELEV_DEM: "4235.6",
      LONGITUDE: "-111.96503",
      UNITS: {
        position: "m",
        elevation: "ft"
      },
      STATE: "UT",
      OBSERVATIONS: {
        date_time: [
          "2015-01-03T00:00:00Z",
          "2015-01-03T00:05:00Z",
          "2015-01-03T00:10:00Z",
          "2015-01-03T00:15:00Z",
          "2015-01-03T00:20:00Z"
        ],
        air_temp_set_1: [
          -5.6,
          -5.6,
          -6.1,
          -6.1,
          -6.7
        ]
      },
      RESTRICTED: false,
      QC_FLAGGED: false,
      LATITUDE: "40.77069",
      TIMEZONE: "America/Denver",
      ID: "53"
    }
  ],
  SUMMARY: {
    DATA_QUERY_TIME: "44.8989868164 ms",
    RESPONSE_CODE: 1,
    RESPONSE_MESSAGE: "OK",
    METADATA_RESPONSE_TIME: "121.969938278 ms",
    DATA_PARSING_TIME: "107.047080994 ms",
    VERSION: "v2.21.0",
    TOTAL_DATA_TIME: "151.947021484 ms",
    NUMBER_OF_OBJECTS: 1,
    FUNCTION_USED: "time_data_parser"
  }
}
  • SUMMARY{}

    • NUMBER_OF_OBJECTS, is a integer value of the number of stations returned.

    • RESPONSE_CODE, is a numerical code indicating the status of the request.

      • “1” = “OK”

      • “2” = “Zero Results”

      • “200” = “Authentication failure”

      • “400” = “Violates a rule of the API”

    • RESPONSE_MESSAGE, is a string explaining the RESPONSE_CODE.

    • VERSION, is the API’s current version number.

    • METADATA_RESPONSE_TIME, is the amount of time it took for the API to query and parse the metadata.

    • DATA_QUERY_TIME, is the amount of time it took for the API to query the data from the database.

    • DATA_PARSING_TIME, is the amount of time it took for the API to format the queried data into output.

    • TOTAL_DATA_TIME, is the amount of time if took for the API to query and parse the data.

    • FUNCTION_USED, is a diagnostic indicator for Synoptic’s developers.

  • STATION[]

    • SENSOR_VARIABLES[], summary of variables in the OBSERVATIONS element.

    • OBSERVATIONS[], contains all the observational data.

    • QC[], contains a time series for each flagged variable (qc_checks). Returns the specified QC IDs at the same time as the flagged observation.

    • QC_FLAGGED, boolean value indicating data check attributes are returned (if requested).

  • QC_SUMMARY{}

    • QC_CHECKS_APPLIED[], a list of data checks that were applied to the data.

    • TOTAL_OBSERVATIONS_FLAGGED, number of observations that have additional data check attributes.

    • PERCENT_OF_TOTAL_OBSERVATIONS_FLAGGED, floating point number indicating the percentage of the observations that have additional data check attributes.

  • UNITS{}

    • A list of the units of each variable in the OBSERVATIONS element.
